CO2 WELDING WIRE

CO2 welding wire

CO2 welding wire

JUL ONG BRAND CO2 WEL .DING WIRE
TYPE:TYPE : ER50-6
EQUAL TO: AWS NORMES EQUIVAL ENTES : ER70S-6
DIN SG2 BS A18
JIS YGW12

1.Chemical Component( %)

C	Si	Mn	P	S	Cu	Other
0.06-0.15	0.8-1.15	1. 4-1.85	≤ 0.025	≤0.035	≤0.50 Y	≤0.50

2.Metallurgy Chemical Performance

Tensile Strength Mpa	Vield Strength Mpa	Elongation (%)	V-tmpactionAbsorbing power (-29"C)J
≥500	≥420	≥22	≥27

3.Wire Diameter And Referance Electric Current

Wire diameter (mm)	0.80	1.00	1.20	1.60
Welding current (A)	40-140	50-220	80-350	120-550
