GALVANIZED STEEL WIRE

Galvanized steel wire(Z2coil for below 1.60mm)Wire Diameter(mm)Tolerance+/-TensileStrength(Mpa)Zinc Coating(G/M2)PackingWeight(Kg/CI)ReferanceStandard0.60-1.501800-240060-120(Bigger Diameter， MoreZinc

Content

Galvanized steel wire(Z2coil for below 1.60mm)

Wire Diameter(mm)	Tolerance+/-	TensileStrength(Mpa)	Zinc Coating(G/M²)	PackingWeight(Kg/CI)	ReferanceStandard
0.60-1.50		1800-2400	60-120(Bigger Diameter， MoreZinc Coating)	50-100Ou400-500	GB8919
1.60-4.80		1200-1400	150-300(Bigger Diameter， MoreZinc Coating)	≤280	ASTM B 498

Note：

packing：soft coil， grail with steel bobbin， grail with cardboard， Z2coil， etc.， bright wire below 1.3mm only can packed in soft coil or Z2 coil； galvanized wire below 1.60mm only can packed in soft coil or Z2 coil， above 1.60mm only can packed in soft coil.
Dimension for grail with steel column can be negotiated； four kinds of dimension for grailwith cardboard：420mm， 440mm， 470mm and 490mm.Out diameter after packing can notover 750mm in order to meet the requirements of the container.
Z2 coil dimension：core diameter of cardboard：：355mm；height of cardboard：280mm； width of the coil rising height of the coil：≤295mm) ， wire outer diameter after packing≤740mm。
pallet dimension：required≤740mmx740mm.
